FEW05 Foldable Electric Wheelchair
Lightweight, Foldable, Portable
| Brand: HEDY | Model: FEW05 | Controller: Top brands | Motor: Brushless |
| Battery: Lithium | Frame Material: 6061 Aluminum Alloy | Load Capacity: 120 KG | Driving Range: 20 KM |
| Speed: 6KM/H | Grade Ability: 10° | Net Weight: 18KG | Rear Tires: 12" PU |
- Foldable electric wheelchair
- 8" rear wheels
- Advanced Lithium-ion Batteries
- Armrests can be lifted up for the convenience of the user
- Adjustable Controller: Right or left mounting
- Electromagnetic brakes engage automatically when joystick is took off and anti-tip on the slope
- Weight: 20KG
- Loading Capacity: 120KG
- Bauhaus Design Without Cables on Outside
- Made of Magnesium Alloy
- 5 Colors Available(Black/Silver/Red/Green/Blue)
| Brand | HEDY | FEW05 |
| Material | 6061 Aluminum Alloy | |
| Unfolded Dimension(LxWxH) | 930x570x860mm | 36.6x22.4x33.9inch |
| Folded Dimension(LxWxH) | 690x570x480mm | 27.2x22.x18.9inch |
| Packing Dimension(LxWxH) | 700x630x510mm | 27.6x24.8x20.1inch |
| Width of Armrests | 450mm | 17.7" |
| Seat Width | 400mm | 15.8inch |
| Seat-to-Floor Height | 510mm | 20.1inch |
| N.W.(Without battery) | 26kg | 57.3lbs |
| Gross Weight | 28kg | 61.7lbs |
| Max Speed | 6km/h | 3.75mph |
| Load Capacity | 120kg | 264.6lbs |
| Motor | DC Brushless Motor | 180Wx2pc |
| Battery | Lithium Battery | 24V 240WH |
| Capacity | 10AH | 20AH(optional) |
| Battery Weight | 2kg | 4.4lbs |
| Driving Range | 15km | 9.3miles |
| Tires | Front Tires: 7.5" PU | Rear Tires: 8" PU |
| Color | Black, Silver, Red, Green, Blue | |
| Turning Radius | 1200mm | 47.2inch |
| Grade Ability | 9° |
-
The wheelchair is for indoor use or outdoor use?
It's suitable for both indoor and outdoor use thanks for its both superb indoor manoeuvrability and outstanding outdoor performance.
-
Can the wheelchair be taken on board (the airplane)?
Yes, it can be taken on board since our battery is MSDS certified and with 10AH capacity.
-
What is the life span of the battery?
The battery can be filled and released for 600-800 times.
-
Can I take overseas trip with this wheelchair?
Yes, it's your perfect companion on your trip because it's lightweight, portable and foldable.
-
How about the warranty?
1). 3 months for cushion and tires
2). 12 months for motor and controller
3). 18 months for battery
4). 36 months for frame -
Can you do ODM or OEM?
Yes, we can provide ODM and OEM services as long as the quantity reaches our MOQ.
